Working Instructions (mech)
1225-1010 Rev 1
Reassembly
Open the slider.
Apply 10 Ncm torque when tightening the two 1.6 mm black
screws with the JCIS bit.
5.4 Screw Sheets
Attach a new Screw Sheet on top of one of the screws.
Press with your finger to make it properly attached.
© Sony Ericsson Mobile Communications AB – Company Internal
61(70)
