Sony Ericsson W705 - 4 Replacement; Battery Cover; Rear Cover; Co-Branding

Working Instructions (mech)
1225-1010 Rev 1
4 Replacement
4.1 Battery Cover
Follow the 3.1 Disassembly instructions!
Prepare the new Battery Cover.
Follow the 5.10 Reassembly instructions!
4.2 Rear Cover
Follow the 3.1 – 3.3 Disassembly instructions!
Prepare the new Rear Cover.
Follow the 5.8 – 5.10 Reassembly instructions!
4.3 Co-Branding
Follow the 3.6 Disassembly instructions!
Prepare the new Co-Branding.
Follow the 5.5 Reassembly instructions!
4.4 Screw Sheet
Follow the 3.7 Disassembly instructions!
Prepare the new Screw Sheets.
Follow the 5.4 Reassembly instructions!
© Sony Ericsson Mobile Communications AB – Company Internal
18(70)
