Sony Ericsson W705 - Rear Cover

Working Instructions (mech)
1225-1010 Rev 1
Reassembly
Apply 10 Ncm torque when tightening the 2.8 mm black
screw with the JCIS bit.
Connect the Loudspeaker by pressing its connector from the
top into the connector of the Main PBA.
Close the slider.
5.8 Rear Cover
Place the Rear Cover on top of the Main PBA in its proper
position.
© Sony Ericsson Mobile Communications AB – Company Internal
66(70)
