Working Instructions (mech)
1225-1010 Rev 1
Replacement
4.22 Gasket SIM
Follow the 3.1 – 3.5 Disassembly instructions!
Carry out the replacement as described below.
Follow the 5.6 – 5.10 Reassembly instructions!
REMOVAL
Use the Front Opening Tool to peel off one or both Gaskets
from the SIM Flex/Carrier Unit.
INSTALLATION
Place the Gaskets in their proper positions and press to
make them securely attached.
© Sony Ericsson Mobile Communications AB – Company Internal
41(70)
