Working Instructions (mech)
1225-1010 Rev 1
Replacement: Camera - Rear
so that it can be removed.
INSTALLATION
Note the keying, camera – socket!
Place the camera inside and in level with the socket,
and press with your fingers, without touching the camera
lens, to the bottom of the socket.
© Sony Ericsson Mobile Communications AB – Company Internal
40(70)
