Working Instructions (mech)
1225-1010 Rev 1
Replacement: Loudspeaker
INSTALLATION
Place the Loudspeaker in its proper position.
Press down with the flat end of the tweezers to make it
securely attached.
Connect the Loudspeaker by pressing its connector from the
top into the Main PBA connector.
© Sony Ericsson Mobile Communications AB – Company Internal
26(70)
