Switch 3: Sets which settings are reset when the RESET switch is pressed.
Switch 4: Enables/disables VISCA and VISCA over IP communication. The settings are applied when the camera is
turned on.
Set to the ON position to use the unit when connected to an RM-IP500 remote controller.
Note
If the administrator password has not been configured, VISCA communication is disabled, regardless of the switch setting. For
details about configuring the administrator password, see “Initializing the Unit.”
Switch 5: Sets the VISCA IN/VISCA OUT connector baud rate. The settings are applied when the camera is turned on.
Switch 6, 7: Reserved. Not used.
Switch 8: Sets the IP address to a specific value.
Switch 1
setting
Switch 2
setting
Description
OFF (default) OFF (default)
Receives operations from the infrared remote control (supplied) with remote
control ID of 1.
Default setting.
OFF ON
Receives operations from the infrared remote control (supplied) with remote
control ID of 2.
ON OFF
Receives operations from the infrared remote control (supplied) with remote
control ID of 3.
ON ON Reserved
Setting Description
OFF
(default)
Resets the network connection settings only. The network settings, security settings, and user
information (user name and password) of the unit will be reset.
ON Resets all settings to factory defaults.
Setting Description
OFF (default) Will not respond to VISCA commands.
ON Accepts VISCA commands.
Setting Description
OFF (default) Sets the baud rate to 9600 bps.
ON Sets the baud rate to 38400 bps.
Setting Description
OFF (default) The user sets the IP address.
