Help Guide
Color Video Camera
BRC-AM7
Outputting an Optical Fiber Signal
You can output an SDI signal converted to an optical signal by connecting an SFP+ module (option) to the OPTICAL
connector of the unit. Use an SFP+ module that matches the signal band of each format.
Signal band
4K (59.94P, 50P): 12G
4K (other than 59.94P, 50P): 6G
HD (59.94P, 50P): 3G
HD (other than 59.94P, 50P): 1.5G
Note
Use a module that complies with the following standards.
SFF standards
SFF-8083 / SFF-8418 / SFF-8419* / SFF-8432 / SFF-8433 / SFF-8071 / SFF-8472
SDI standards
ST297 / ST292 / ST424 / ST425 / ST2081 / ST2082
The same signal as the SDI OUT 1 connector is output to the SFP+ module.
The unit does not support optical fiber signal input.
Use an SFP+ module for optical fiber signal output. For details about verified SFP+ modules, contact your dealer or Sony service
representative.
TP1001804712
5-065-326-11(1) Copyright 2024 Sony Corporation
* Power Level I (1.0 W)
