Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
101
HCD-CL5MD
L143 1-412-029-11 INDUCTOR CHIP 10uH
L144 1-412-032-11 INDUCTOR CHIP 100uH
L145 1-412-032-11 INDUCTOR CHIP 100uH
L146 1-469-855-21 FERRITE 0uH
L147 1-469-855-21 FERRITE 0uH
L161 1-500-245-11 FERRITE 0uH
L171 1-500-245-11 FERRITE 0uH
L180 1-469-855-21 FERRITE 0uH
L181 1-469-855-21 FERRITE 0uH
L182 1-500-245-11 FERRITE 0uH
L183 1-216-296-11 SHORT 0
L184 1-216-296-11 SHORT 0
< TRANSISTOR >
Q101 8-729-403-35 TRANSISTOR UN5113-TX
Q121 8-729-403-35 TRANSISTOR UN5113-TX
Q122 8-729-101-07 TRANSISTOR 2SB798-T1DK
Q131 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q132 8-729-903-10 TRANSISTOR FMW1-T-148
Q133 8-729-402-93 TRANSISTOR UN5214-TX
Q134 8-729-402-93 TRANSISTOR UN5214-TX
Q181 8-729-018-75 TRANSISTOR 2SJ278MYTR
Q182 8-729-017-65 TRANSISTOR 2SK1764KYTR
< RESISTOR >
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R102 1-216-853-11 METAL CHIP 470K 5% 1/16W
R103 1-216-863-11 RES-CHIP 3.3M 5% 1/16W
R104 1-216-853-11 METAL CHIP 470K 5% 1/16W
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R107 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R108 1-216-833-11 METAL CHIP 10K 5% 1/16W
R109 1-216-845-11 METAL CHIP 100K 5% 1/16W
R110 1-216-845-11 METAL CHIP 100K 5% 1/16W
R111 1-216-833-11 METAL CHIP 10K 5% 1/16W
R112 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R113 1-216-833-11 METAL CHIP 10K 5% 1/16W
R114 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R115 1-216-833-11 METAL CHIP 10K 5% 1/16W
R116 1-216-839-11 METAL CHIP 33K 5% 1/16W
R117 1-216-837-11 METAL CHIP 22K 5% 1/16W
R118 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R119 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R120 1-218-889-11 METAL CHIP 56K 0.5% 1/16W
R121 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R122 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R123 1-216-819-11 METAL CHIP 680 5% 1/16W
R124 1-216-809-11 METAL CHIP 100 5% 1/16W
R125 1-216-815-11 METAL CHIP 330 5% 1/16W
R126 1-216-819-11 METAL CHIP 680 5% 1/16W
R127 1-216-845-11 METAL CHIP 100K 5% 1/16W
R128 1-219-724-11 METAL CHIP 1 1% 1/4W
R129 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R131 1-216-833-11 METAL CHIP 10K 5% 1/16W
R132 1-216-839-11 METAL CHIP 33K 5% 1/16W
R133 1-216-821-11 METAL CHIP 1K 5% 1/16W
R134 1-216-821-11 METAL CHIP 1K 5% 1/16W
R135 1-216-821-11 METAL CHIP 1K 5% 1/16W
R136 1-216-302-00 METAL CHIP 2.7 5% 1/10W
R138 1-216-833-11 METAL CHIP 10K 5% 1/16W
R150 1-216-833-11 METAL CHIP 10K 5% 1/16W
R151 1-216-833-11 METAL CHIP 10K 5% 1/16W
R153 1-216-833-11 METAL CHIP 10K 5% 1/16W
R155 1-216-864-11 SHORT 0
R156 1-216-864-11 SHORT 0
R158 1-216-809-11 METAL CHIP 100 5% 1/16W
R162 1-216-833-11 METAL CHIP 10K 5% 1/16W
R167 1-216-833-11 METAL CHIP 10K 5% 1/16W
R168 1-216-845-11 METAL CHIP 100K 5% 1/16W
R169 1-216-855-11 METAL CHIP 680K 5% 1/16W
R170 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R171 1-216-821-11 METAL CHIP 1K 5% 1/16W
R173 1-216-821-11 METAL CHIP 1K 5% 1/16W
R174 1-216-811-11 METAL CHIP 150 5% 1/16W
R177 1-216-805-11 METAL CHIP 47 5% 1/16W
R179 1-216-295-11 SHORT 0
R181 1-216-841-11 METAL CHIP 47K 5% 1/16W
R182 1-216-841-11 METAL CHIP 47K 5% 1/16W
R183 1-216-841-11 METAL CHIP 47K 5% 1/16W
R184 1-220-942-11 METAL CHIP 3.3 1% 1/4
R185 1-220-942-11 METAL CHIP 3.3 1% 1/4
R195 1-216-833-11 METAL CHIP 10K 5% 1/16W
R196 1-216-833-11 METAL CHIP 10K 5% 1/16W
R197 1-216-833-11 METAL CHIP 10K 5% 1/16W
R218 1-216-864-11 SHORT 0
< SWITCH >
S101 1-762-596-21 SWITCH, PUSH (1 KEY) (LIMIT IN SW)
S102 1-771-957-11 SWITCH, PUSH (2 KEY) (REFRECT PROTECT)
S103 1-771-956-21 SWITCH, PUSH (1 KEY) (OUT SW)
S104 1-771-955-21 SWITCH, PUSH (1 KEY) (PLAY SW)
S105 1-771-955-21 SWITCH, PUSH (1 KEY) (REC SW)
< VIBRATOR >
X171 1-781-569-21 OSCILLATOR, CRYSTAL 90MHz
************************************************************
A-4476-086-A DIGITAL BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-126-934-11 ELECT 220uF 20.00% 10V
C1002 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1003 1-126-933-11 ELECT 100uF 20.00% 16V
C1004 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1005 1-126-933-11 ELECT 100uF 20.00% 16V
C1006 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1007 1-126-933-11 ELECT 100uF 20.00% 16V
C1008 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1009 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1010 1-126-933-11 ELECT 100uF 20.00% 16V
C1011 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1012 1-126-933-11 ELECT 100uF 20.00% 16V
C1013 1-126-933-11 ELECT 100uF 20.00% 16V
C1014 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1015 1-126-933-11 ELECT 100uF 20.00% 16V
BD (MD) DIGITAL
