Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
97
SECTION 9
ELECTRICAL PARTS LIST
HCD-CL5MD
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
• Abbreviation
AUS : Australian model
HK : Hong Kong model
A-4475-465-A AMP BOARD, COMPLETE (AEP,UK)
****************************
A-4475-485-A AMP BOARD, COMPLETE (AUS,HK)
****************************
< CAPACITOR >
C801 1-126-964-11 ELECT 10uF 20.00% 50V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-965-11 ELECT 22uF 20.00% 50V
C805 1-136-161-00 FILM 0.047uF 5.00% 50V
C806 1-136-161-00 FILM 0.047uF 5.00% 50V
C807 1-136-153-00 FILM 0.01uF 5% 50V
(AEP,UK)
C808 1-136-153-00 FILM 0.01uF 5% 50V
(AEP,UK)
C809 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
(AEP,UK)
C810 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
(AEP,UK)
C811 1-107-713-11 ELECT 4.7uF 20.00% 50V
C832 1-104-665-11 ELECT 100uF 20.00% 10V
C833 1-126-961-11 ELECT 2.2uF 20.00% 50V
C834 1-104-665-11 ELECT 100uF 20.00% 10V
C851 1-126-964-11 ELECT 10uF 20.00% 50V
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-965-11 ELECT 22uF 20.00% 50V
C855 1-136-161-00 FILM 0.047uF 5.00% 50V
C856 1-136-161-00 FILM 0.047uF 5.00% 50V
C857 1-136-153-00 FILM 0.01uF 5% 50V
(AEP,UK)
C858 1-136-153-00 FILM 0.01uF 5% 50V
(AEP,UK)
C859 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
(AEP,UK)
C861 1-107-713-11 ELECT 4.7uF 20.00% 50V
C891 1-126-959-11 ELECT 0.47uF 20.00% 50V
C951 1-137-844-11 ELECT 2200uF 20% 42V
(AEP,UK)
C951 1-135-832-11 ELECT 2200uF 20% 50V
(AUS,HK)
C952 1-137-844-11 ELECT 2200uF 20% 42V
(AEP,UK)
C952 1-135-832-11 ELECT 2200uF 20% 50V
(AUS,HK)
C953 1-136-165-00 FILM 0.1uF 5.00% 50V
C954 1-136-165-00 FILM 0.1uF 5.00% 50V
C957 1-136-153-00 FILM 0.01uF 5% 50V
C958 1-136-153-00 FILM 0.01uF 5% 50V
C971 1-126-965-11 ELECT 22uF 20.00% 50V
C972 1-126-965-11 ELECT 22uF 20.00% 50V
C973 1-104-665-11 ELECT 100uF 20.00% 10V
C974 1-126-967-11 ELECT 47uF 20.00% 50V
C975 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
(AEP,UK)
C991 1-126-963-11 ELECT 4.7uF 20.00% 50V
< CONNECTOR >
CN801 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN952 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D891 8-719-911-19 DIODE 1SS133T-72
D953 8-719-024-99 DIODE 11ES2-NTA2B
D954 8-719-024-99 DIODE 11ES2-NTA2B
D955 8-719-024-99 DIODE 11ES2-NTA2B
D956 8-719-024-99 DIODE 11ES2-NTA2B
D957 8-719-024-99 DIODE 11ES2-NTA2B
D958 8-719-024-99 DIODE 11ES2-NTA2B
D959 8-719-024-99 DIODE 11ES2-NTA2B
D960 8-719-024-99 DIODE 11ES2-NTA2B
D961 8-719-911-19 DIODE 1SS133T-72
D962 8-719-911-19 DIODE 1SS133T-72
D971 8-719-911-19 DIODE 1SS133T-72
D991 8-719-911-19 DIODE 1SS133T-72
< EARTH >
* EP951 1-537-738-21 TERMINAL, EARTH
< IC >
IC801 8-749-016-93 IC STK402-070S
< COIL >
L801 1-420-872-00 COIL, AIR-CORE (AEP,UK)
L851 1-420-872-00 COIL, AIR-CORE (AEP,UK)
AMP
