13
HCD-CL5MD
3-4. PANEL BOARD
3-5. MD MECHANISM
1
Flat cable (27 core)
(CN102)
2
Flat cable (17 core)
(CN103)
5
Two screws
(
+BVTTWH M3
)
5
Two screws
(
+BVTTWH M3
)
4
Digital board
6
MD mechanism
(MDM-7B)
7
Two insulators
7
Two insulators
3
Two screws
(
+BVTP 3 × 8
)
1
Two screws
(
+BVTP 2.6 × 8
)
2
MD mechanism
7
Four screws
(
+BVTP 2.6 × 8
)
8
Six screws
(
+BVTP 2.6 × 8
)
9
Panel board
8
Eight screws
(
+BVTP 2.6 × 8
)
qa
Ring SW board
5
Knob (vol)
6
Nut
q;
Two screws
(+BVTP
2.6 × 8
)
3
Two screws
(
+BVTP 3 × 8
)
4
Shield (MD)
