7-7. PRINTED WIRING BOARD CD SECTION
IC101
IC104
IC103
IC102
(Page 69)
(A-MAX.3)
Ref. No. Location
D101 D-2
IC101 C-2
IC102 A-3
IC103 C-1
Q101 C-1
Q102 B-1
Q103 D-3
• Semiconductor
Location
• See page 45 for Circuit Boards Location.
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
