Sony HCD-CL5MD - Over Light Head (HR901), BD (MD) Board; Holder Assy

14
HCD-CL5MD
3-6. OVER LIGHT HEAD (HR901), BD (MD) BOARD
3-7. HOLDER ASSY
6
2 S crew ( P 1.7 × 6)
5
S crew ( 2 × 6)
3
Over light head ( HR901)
8
BD ( MD) board
1
Connector ( CN104)
7
Flexible board ( CN101)
4 Remove the solder (four portions).
4 Remove the solder (five portions).
3
4
5 Holder assy
1 Tension spring (holder)
2 Claw
