Sony HCD-CL5MD - CD Base Unit (BU-30 BD61); CD Optical Pick-Up (A-MAX.3)

19
HCD-CL5MD
3-16. CD BASE UNIT (BU-30BD61)
3-17. CD OPTICAL PICK-UP (A-MAX.3)
1 Flat cable (22 core)
(CN101)
qa CD base unit
(BU-30BD61)
2 Two screws (BVTP2.6 × 8)
5 Floating screw (PTPWH M2.6
)
8 Floating screw (DIA.12)
q; Insulator
q; Two Insulators
q; Insulator
3 Two stoppers
4 Two coil springs (Insulators)
7 Coil spring (Insulator)
9 Cone coil spring
6 Washer
1 Flat cable (16 core)
2 Sled shaft
3 MD Optical pick-up (A-MAX.3)
