Sony HCD-CL5MD - Base Unit Section

96
HCD-CL5MD
8-8. BASE UNIT SECTION
0 601 A-4735-059-A CD OPTICAL PICK-UP (A-MAX.3)
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
603 A-4725-528-A BD(CD)BOARD, COMPLETE
604 4-233-831-01 GEAR (LA)
605 4-233-832-01 GEAR (LB)
606 7-627-853-28 SCREW, PRECISION +P 2X3 TYPE3
607 3-531-576-11 RIVET
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
not supplied
not supplied
602
607
604
605
606
606
not supplied
601
603
