Sony HCD-CL5MD - MD Optical Pick-Up (KMS-260 B;K1 NP); Spindle Motor Assy

16
HCD-CL5MD
3-10. MD OPTICAL PICK-UP (KMS-260B/K1NP)
3-11. SPINDLE MOTOR ASSY
8
6 Two s crews ( +KPT2 × 6)
4
S crew ( CZN2 × 6
)
2 S crew ( M1.7, TAPPING)
9
S crew (+ P1.7 × 6)
1
Flexible PWB
q;
SL base
5
Base (BU-A)
3 Gear
(SD)
qa
MD Optical pick-up (KMS-260B/K1NP)
7
Main shaft
1 Three s crews ( M1.7, TAPPING
)
2 Spindle motor assy (M101)
