Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
99
HCD-CL5MD
A-4725-528-A BD(CD) BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C109 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-126-607-11 ELECT CHIP 47uF 20% 4V
C113 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C117 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C120 1-126-607-11 ELECT CHIP 47uF 20% 4V
C151 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C153 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C164 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C165 1-124-779-00 ELECT CHIP 10uF 20% 16V
C166 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C182 1-128-995-11 ELECT CHIP 100uF 20% 10V
C201 1-126-246-11 ELECT CHIP 220uF 20% 4V
C202 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C203 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C204 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C205 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C212 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C221 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C222 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C224 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C227 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C228 1-115-156-11 CERAMIC CHIP 1uF 10V
C229 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C231 1-128-995-11 ELECT CHIP 100uF 20% 10V
C234 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C235 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C236 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C237 1-162-919-11 CERAMIC CHIP 22PF 50V
C240 1-163-038-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-784-873-21 CONNECTOR,FFC(LIF(NON-ZIF))22P
CN102 1-794-424-11 CONNECTOR, FCC/FPC 16P
< DIODE >
D101 8-719-422-12 DIODE UDZ-TE-17-3.9B
< FERRITE BEAD >
FB101 1-500-445-11 FERRITE 0uH
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC102 8-759-713-70 IC AN41020A
IC103 8-752-089-74 IC CXA2581N-T4
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-RT1
Q102 8-729-424-08 TRANSISTOR UN2111-TX
Q103 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R102 1-216-077-00 RES-CHIP 15K 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-077-00 RES-CHIP 15K 5% 1/10W
R105 1-216-049-11 RES-CHIP 1K 5% 1/10W
R109 1-216-099-00 METAL CHIP 120K 5% 1/10W
R111 1-216-099-00 METAL CHIP 120K 5% 1/10W
R113 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R114 1-218-745-11 RES-CHIP 160K 5% 1/16W
R115 1-216-085-00 METAL CHIP 33K 5% 1/10W
R116 1-216-085-00 METAL CHIP 33K 5% 1/10W
R118 1-216-295-11 SHORT 0
R120 1-216-099-00 METAL CHIP 120K 5% 1/10W
R122 1-216-097-11 RES-CHIP 100K 5% 1/10W
R123 1-216-001-00 METAL CHIP 10 5% 1/10W
R124 1-216-001-00 METAL CHIP 10 5% 1/10W
R125 1-216-085-00 METAL CHIP 33K 5% 1/10W
R126 1-216-085-00 METAL CHIP 33K 5% 1/10W
R151 1-216-097-11 RES-CHIP 100K 5% 1/10W
R152 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R163 1-216-295-11 SHORT 0
R164 1-216-295-11 SHORT 0
R167 1-216-295-11 SHORT 0
R168 1-216-295-11 SHORT 0
R176 1-216-295-11 SHORT 0
R179 1-216-295-11 SHORT 0
R201 1-216-085-00 METAL CHIP 33K 5% 1/10W
R202 1-216-073-00 METAL CHIP 10K 5% 1/10W
R203 1-216-097-11 RES-CHIP 100K 5% 1/10W
R204 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R205 1-216-049-11 RES-CHIP 1K 5% 1/10W
R206 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R207 1-216-121-11 RES-CHIP 1M 5% 1/10W
R212 1-216-033-00 METAL CHIP 220 5% 1/10W
R213 1-216-295-11 SHORT 0
R214 1-216-295-11 SHORT 0
R215 1-216-295-11 SHORT 0
R216 1-216-033-00 METAL CHIP 220 5% 1/10W
R217 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R218 1-216-049-11 RES-CHIP 1K 5% 1/10W
R219 1-216-049-11 RES-CHIP 1K 5% 1/10W
R220 1-216-295-11 SHORT 0
R221 1-216-033-00 METAL CHIP 220 5% 1/10W
R226 1-216-025-11 RES-CHIP 100 5% 1/10W
R227 1-216-097-11 RES-CHIP 100K 5% 1/10W
R228 1-216-113-00 METAL CHIP 470K 5% 1/10W
BD (CD)
