Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
98
HCD-CL5MD
< TRANSISTOR >
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q831 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q832 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q833 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q834 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q835 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q836 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q837 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q841 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q842 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q881 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q882 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q971 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q972 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q973 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-419-11 CARBON 1.5K 5% 1/4W F
R804 1-249-437-11 CARBON 47K 5% 1/4W
0R805 1-233-352-11 ENCAPSULATED COMPONENT
R806 1-260-076-11 CARBON 10 5% 1/2W
R807 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK)
R808 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK)
R810 1-249-417-11 CARBON 1K 5% 1/4W F
R811 1-249-431-11 CARBON 15K 5% 1/4W
R812 1-249-441-11 CARBON 100K 5% 1/4W
R813 1-249-437-11 CARBON 47K 5% 1/4W
R814 1-249-438-11 CARBON 56K 5% 1/4W
R815 1-249-433-11 CARBON 22K 5% 1/4W
R816 1-215-889-00 METAL OXIDE 330 5% 2W
R833 1-249-425-11 CARBON 4.7K 5% 1/4W F
R834 1-249-435-11 CARBON 33K 5% 1/4W
R835 1-249-433-11 CARBON 22K 5% 1/4W
R836 1-249-429-11 CARBON 10K 5% 1/4W
R837 1-249-429-11 CARBON 10K 5% 1/4W
R839 1-249-441-11 CARBON 100K 5% 1/4W
R841 1-249-441-11 CARBON 100K 5% 1/4W
R842 1-249-441-11 CARBON 100K 5% 1/4W
R843 1-249-441-11 CARBON 100K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-419-11 CARBON 1.5K 5% 1/4W F
R854 1-249-437-11 CARBON 47K 5% 1/4W
0R855 1-233-352-11 ENCAPSULATED COMPONENT
R856 1-260-076-11 CARBON 10 5% 1/2W
R857 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK)
R858 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK)
R860 1-249-417-11 CARBON 1K 5% 1/4W F
R861 1-249-431-11 CARBON 15K 5% 1/4W
R862 1-249-441-11 CARBON 100K 5% 1/4W
R863 1-249-437-11 CARBON 47K 5% 1/4W
R864 1-249-437-11 CARBON 47K 5% 1/4W
R865 1-249-433-11 CARBON 22K 5% 1/4W
R866 1-215-889-00 METAL OXIDE 330 5% 2W
0R881 1-215-890-11 METAL OXIDE 470 5% 2W
R882 1-249-429-11 CARBON 10K 5% 1/4W
R883 1-249-429-11 CARBON 10K 5% 1/4W
R884 1-249-429-11 CARBON 10K 5% 1/4W
R885 1-249-441-11 CARBON 100K 5% 1/4W
R891 1-249-429-11 CARBON 10K 5% 1/4W
R892 1-249-441-11 CARBON 100K 5% 1/4W
R893 1-247-903-00 CARBON 1M 5% 1/4W
R898 1-249-441-11 CARBON 100K 5% 1/4W
R899 1-249-429-11 CARBON 10K 5% 1/4W
R951 1-249-425-11 CARBON 4.7K 5% 1/4W F
R952 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R971 1-212-881-11 FUSIBLE 100 5% 1/4W
0R972 1-212-881-11 FUSIBLE 100 5% 1/4W
R973 1-249-435-11 CARBON 33K 5% 1/4W
R974 1-249-433-11 CARBON 22K 5% 1/4W
R975 1-249-437-11 CARBON 47K 5% 1/4W
R976 1-249-441-11 CARBON 100K 5% 1/4W
R977 1-249-421-11 CARBON 2.2K 5% 1/4W F
R978 1-249-433-11 CARBON 22K 5% 1/4W
R979 1-249-421-11 CARBON 2.2K 5% 1/4W F
R980 1-249-429-11 CARBON 10K 5% 1/4W
R981 1-249-429-11 CARBON 10K 5% 1/4W
0R982 1-202-972-61 FUSIBLE 1 5% 1/4W
< RELAY >
RY801 1-515-920-11 RELAY (24V)
< TERMINAL >
TM801 1-694-677-11 TERMINAL BOARD (4P) (SPEAKER)
************************************************************
1-679-981-11 BACK LIGHT BOARD
****************
< CAPACITOR >
C709 1-126-935-11 ELECT 470uF 20.00% 10V
< CONNECTOR >
CN771 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D771 8-719-075-50 DIODE SELS6B14C-TP6 (BACK LIGHT)
D772 8-719-075-50 DIODE SELS6B14C-TP6 (BACK LIGHT)
D773 8-719-075-50 DIODE SELS6B14C-TP6 (BACK LIGHT)
D774 8-719-075-50 DIODE SELS6B14C-TP6 (BACK LIGHT)
D775 8-719-075-50 DIODE SELS6B14C-TP6 (BACK LIGHT)
D776 8-719-075-50 DIODE SELS6B14C-TP6 (BACK LIGHT)
< RESISTOR >
R771 1-249-409-11 CARBON 220 5% 1/4W F
R772 1-249-409-11 CARBON 220 5% 1/4W F
R773 1-249-409-11 CARBON 220 5% 1/4W F
************************************************************
AMP BACK LIGHT
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
