Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
110
HCD-CL5MD
1-680-256-11 TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C901 1-136-165-00 FILM 0.1uF 5.00% 50V
C902 1-136-165-00 FILM 0.1uF 5.00% 50V
C931 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P (AEP,UK,AUS)
* CN902 1-564-523-11 PLUG, CONNECTOR 8P
* CN903 1-568-942-11 PIN, CONNECTOR 4P
* CN904 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D901 8-719-028-23 DIODE D3SBA20-4101
D934 8-719-911-19 DIODE 1SS133T-72
< FUSE >
0F901 1-533-466-11 FUSE, GLASS TUBE (DIA. 5)1.25A/250V
(AEP,UK)
0F901 1-533-469-11 FUSE, GLASS TUBE (DIA. 5)2.5A/250V (HK)
0F902 1-533-466-11 FUSE, GLASS TUBE (DIA. 5)1.25A/250V (HK)
0F903 1-533-466-11 FUSE, GLASS TUBE (DIA. 5)1.25A/250V
(HK,AUS)
< TRANSISTOR >
Q931 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q932 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q933 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
0R901 1-219-119-81 FUSIBLE 0.1 5% 1/4W
0R902 1-219-119-81 FUSIBLE 0.1 5% 1/4W
R931 1-249-421-11 CARBON 2.2K 5% 1/4W F
R932 1-249-421-11 CARBON 2.2K 5% 1/4W F
R933 1-249-415-11 CARBON 680 5% 1/4W F
************************************************************
1-678-457-11 TRAY SENSOR BOARD
******************
< CAPACITOR >
C731 1-164-159-11 CERAMIC 0.1uF 50V
< IC >
IC731 8-749-081-01 PHOTO SENSOR DG-264
IC732 8-749-081-01 PHOTO SENSOR DG-264
IC733 8-749-081-01 PHOTO SENSOR DG-264
< RESISTOR >
R731 1-247-876-11 CARBON 75K 5% 1/4W
R732 1-249-408-11 CARBON 180 5% 1/4W F
R733 1-247-876-11 CARBON 75K 5% 1/4W
R734 1-249-408-11 CARBON 180 5% 1/4W F
R735 1-247-876-11 CARBON 75K 5% 1/4W
R736 1-249-408-11 CARBON 180 5% 1/4W F
************************************************************
1-680-258-11 VOL SEL BOARD (HK)
*****************
< CONNECTOR >
CN941 1-568-106-11 PIN, CONNECTOR 4P
CN942 1-564-321-00 PIN, CONNECTOR 2P
CN943 1-774-108-11 PIN, CONNECTOR (PC BOARD)
< SWITCH >
0S943 1-786-055-11 SELECTOR, VOLTAGE (VOLTAGE SLECTOR)
************************************************************
MISCELLANEOUS
**************
5 1-769-910-11 WIRE (FLAT TYPE) (9 CORE)
6 1-693-529-11 TUNER
7 1-769-944-11 WIRE (FLAT TYPE) (11 CORE) (AUS,HK)
7 1-773-008-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
11 1-763-072-11 FAN, DC
60 1-804-260-11 DISPLAY PANEL, LIQUID CRYSTAL
64 1-775-152-11 WIRE (FLAT TYPE) (17 CORE)
65 1-775-237-11 WIRE (FLAT TYPE) (27 CORE)
67 1-773-207-11 WIRE (FLAT TYPE) (25 CORE)
101 1-773-214-11 WIRE (FLAT TYPE) (25 CORE)
0109 1-777-071-81 CORD, POWER (AEP,HK)
0109 1-783-203-11 CORD, POWER (AUS)
0109 1-790-226-11 CORD, POWER (UK)
0112 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
357 1-678-514-11 PWB, FLEXIBLE
577 1-757-574-11 WIRE (FLAT TYPE) (22 CORE)
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0T901 1-435-833-11 TRANSFORMER, POWER (AEP,UK)
0T901 1-435-834-11 TRANSFORMER, POWER (AUS,HK)
HR901 1-500-670-11 HEAD, OVER LIGHT
S102 1-771-957-11 SWITCH, PUSH (2 KEY)
M721 1-541-632-12 MOTOR, DC
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-881-09 SCREW +BVTT 4X8 (S)
#6 7-685-850-04 SCREW +BVTT 2X3 (S)
#7 7-685-204-19 SCREW +KTP 2X6 TYPE2 NON-SLIT
TRANS TRAY SENSOR VOL SEL
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
