HCD-CL5MD
• WAVEFORMS
– BD (CD) SECTION –
– MAIN SECTION –
– MD DIGITAL SECTION –– BD (MD) SECTION –
1 IC101 eh (RF)
2 IC101 ef (FE)
(Play mode)
3 IC101 wh (TE)
(Play mode)
4 IC151 o; (FS4)
1.3Vp-p
0.2Vp-p
1.6Vp-p
3.5Vp-p
176.4kHz
1 IC101 t;
RFAC
2 IC101 ra
TE
3 IC101 el
FE
4 IC101 wg
MDP
5 IC101 us
XTAO
1.3Vp-p
2.2Vp-p
7.5µsec
0.5Vp-p
0.5Vp-p
5Vp-p
33.8MHz
1 IC1001 w;
XOUT
3.5Vp-p
10.0MHz
1 IC401 qa
3.0Vp-p
32.768kHz
4.2Vp-p
2 IC401 qd
16MHz
