Sony HCD-FL5D - Chassis Section-4

122
HCD-FL5D
9-9. CHASSIS SECTION-4
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
451 4-225-252-01 CUSHION (FOOT)
452 A-4676-782-A SP RELAY BOARD, COMPLETE
0 453 1-569-008-21 ADAPTOR, CONVERSION (EA, SP)
* 454 3-703-244-00 BUSHING (2104), CORD (AUS, EA, SP)
454 3-703-571-11 BUSHING (S) (4516), CORD (MX, TH)
0 455 1-777-071-83 CORD, POWER (EA, SP)
0 455 1-783-203-12 CORD, POWER (AUS)
0 455 1-791-901-22 CORD, POWER (MX, TH)
M801 1-763-488-51 FAN, DC
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
451
452
455
453
454
#1
not supplied
not supplied
M801
#1
#1
#1
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
