Sony HCD-FL5D - Printed Wiring Board - RF Board

HCD-FL5D
4444
8-8. PRINTED WIRING BOARD – RF Board – • See page 43 for Circuit Boards Location.
(COMPONENT SIDE)
RF BOARD
(CONDUCTOR SIDE)
RF BOARD
IC001
MB BOARD
CN501
A
E
E
OPTICAL
TRAVERSE
UNIT
(DBU-1)
FLEXIBLE BOARD
1-684-822-
11
(11)
1-684-822-
11
(11)
1
16
17 32
48
33
64 49
1 2 3 4 5 6 7 8 9 10 11 12 13
A
B
C
D
E
F
• Semiconductor
Location
Ref. No. Location
D001 C-11
D002 B-11
IC001 D-11
Q001 B-3
Q002 B-3
(Page 46)
