Sony HCD-FL5D - Schematic Diagram - SW Board

HCD-FL5D
5959
E
MC BOARD
CN109
[3.3]
[3.3]
[∗] {2.9}
<<2.9>>
[1.5]
{∗} <<∗>>
(CAPSTAN)
CAPSTAN MOTOR
CONTROL SWITCH
TAPE SPEED
(NORMAL)
TAPE SPEED
(HIGH)
ROTATION
DETECT
SENSOR (DECK A)
ROTATION
DETECT
SENSOR (DECK B)
+3.3V
+3.3V
CAPM
−
CAPM+
CAPMH/L
ATRGM+
TRGMGND
BTRGM+
S1001
(DECK A PLAY)
S1002
(DECK B PLAY)
S1003
(DECK A HALF)
S1005
(DECK A REC)
S1006
(DECK B HALF)
S1009
(DECK B REC)
C1001
33
10V
PM902
(DECK B)
PM901
(DECK A)
+3.3V
+3.3V
8-22. SCHEMATIC DIAGRAM – SW Board –
•Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : TUNER
(Page 63)
