8-34. PRINTED WIRING BOARD – FRONT REAR AMP Board – • See page 43 for Circuit Boards Location.
Q401 B-6
Q419 C-6
Q420 C-6
Q421 B-6
Q422 B-6
Q423 C-4
Q431 B-9
Q451 C-4
Q471 B-8
Q472 B-9
Q481 C-7
Ref. No. LocationRef. No. Location
D401 B-5
D402 C-5
D421 C-3
D431 B-8
D432 C-8
D451 B-5
D452 C-5
D481 B-8
D482 C-8
D491 B-2
IC401 D-5
IC431 D-8
• Semiconductor Location
