Sony HCD-FL5D - DSP Board Removal; DVD Mechanism Deck Disassembly

16
HCD-FL5D
3-13. DVD MECHANISM DECK (CDM53N-DVBU14)
3-12. DSP BOARD
1 wire (flat type) (9 core
)
(CN603)
2 wire (flat type) (19 core)
(CN602)
3 wire (flat type) (11 core)
(CN601)
4 two screws
(BVTP3
× 8)
5 DSP boar
d
2 two screws
(BVTP 3
× 8)
1 two screws
(BVTP 3
× 8)
3 bracket top panel
7 chassis (CDM) section
6
5
wire (flat type) (29core)
(CN501)
4 four screws
(BVTP 3
× 8)
8 DVD mechanism deck
(CDM53N-DVBU14)
