Sony HCD-FL5D - Page 142

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
142
HCD-FL5D
C918 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C924 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C925 1-126-395-11 ELECT 22uF 20% 16V
C926 1-126-246-11 ELECT CHIP 220uF 20% 4V
C927 1-164-947-11 CERAMIC CHIP 0.01uF 50V
C928 1-117-370-11 CERAMIC CHIP 10uF 10V
< CONNECTOR >
CN201 1-784-364-21 CONNECTOR, FFC/FPC 4P
CN204 1-784-376-11 CONNECTOR, FFC/FPC 17P
CN501 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
* CN901 1-764-177-11 PIN, CONNECTOR (SMD) (1.5mm) 7P
CN905 1-794-032-21 PIN, CONNECTOR (PC BOARD) 11P
CN907 1-793-989-21 CONNECTOR, FFC/FPC 13P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-988-61 DIODE 1SS355TE-17
< FILTER >
FL202 1-234-177-21 FERRITE 0uH
FL203 1-234-177-21 FERRITE 0uH
FL204 1-234-177-21 FERRITE 0uH
FL205 1-234-177-21 FERRITE 0uH
FL501 1-234-177-21 FERRITE 0uH
FL502 1-234-177-21 FERRITE 0uH
FL701 1-234-177-21 FERRITE 0uH
FL702 1-234-177-21 FERRITE 0uH
FL703 1-234-177-21 FERRITE 0uH
FL704 1-234-177-21 FERRITE 0uH
FL705 1-234-177-21 FERRITE 0uH
FL706 1-234-177-21 FERRITE 0uH
FL803 1-234-177-21 FERRITE 0uH
FL901 1-234-177-21 FERRITE 0uH
FL908 1-234-177-21 FERRITE 0uH
< IC >
IC202 6-702-368-01 IC MT48LC4M32B2-7
IC203 8-759-668-01 IC BR9040F-D-E2
IC204 6-802-832-01 IC MR27V3202F-KUTPZ060 (TYPE B)
IC205 (not supplied) IC MBM29DL324BE-90PFTN (TYPE A)
IC206 6-700-404-01 IC ZIVA-5P-B0
IC210 6-700-398-01 IC uPC2918T-E1
IC215 6-700-437-01 IC SN74ALVCH16841DGGR
IC501 6-702-157-01 IC FAN8035L
IC503 8-759-701-40 IC NJM3404AM-TE2
IC509 8-752-408-73 IC CXD3068Q
IC701 6-703-552-01 IC CXD1882R
IC703 8-759-701-40 IC NJM3404AM-TE2
IC706 8-759-564-30 IC MSM51V18165F-60TSKR1
IC901 8-752-933-58 IC CXP973064-224R
IC902 8-759-058-64 IC TC7S32FU-TE85L
IC903 8-759-640-41 IC BR24C08F-E2
IC904 8-759-083-94 IC TC7W74FU (TE12R)
IC906 6-700-407-01 IC SM8707GV-G-E2
IC907 8-759-583-47 IC uPC2933T-E2
< SHORT >
JW303 1-218-990-11 SHORT CHIP 0
JW305 1-218-990-11 SHORT CHIP 0
< COIL >
L801 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q201 8-729-929-26 TRANSISTOR DTC114TE-TL
Q901 8-729-929-26 TRANSISTOR DTC114TE-TL
Q903 8-729-025-28 FET 2SK1828TE85L
Q904 8-729-025-28 FET 2SK1828TE85L
< RESISTOR >
R206 1-218-990-11 SHORT CHIP 0
R212 1-208-643-11 RES-CHIP 22 5% 1/10W
R213 1-218-990-11 SHORT CHIP 0
R214 1-218-990-11 SHORT CHIP 0
R215 1-218-935-11 RES-CHIP 33 5% 1/10W
R216 1-218-935-11 RES-CHIP 33 5% 1/10W
R217 1-218-935-11 RES-CHIP 33 5% 1/10W
R218 1-218-935-11 RES-CHIP 33 5% 1/10W
R219 1-218-935-11 RES-CHIP 33 5% 1/10W
R220 1-218-935-11 RES-CHIP 33 5% 1/10W
R221 1-218-935-11 RES-CHIP 33 5% 1/10W
R222 1-218-935-11 RES-CHIP 33 5% 1/10W
R223 1-218-935-11 RES-CHIP 33 5% 1/10W
R224 1-218-935-11 RES-CHIP 33 5% 1/10W
R225 1-218-935-11 RES-CHIP 33 5% 1/10W
R226 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R227 1-218-935-11 RES-CHIP 33 5% 1/10W
R228 1-218-935-11 RES-CHIP 33 5% 1/10W
R229 1-218-935-11 RES-CHIP 33 5% 1/10W
R230 1-218-935-11 RES-CHIP 33 5% 1/10W
R231 1-218-935-11 RES-CHIP 33 5% 1/10W
R232 1-218-990-11 SHORT CHIP 0
R233 1-218-965-11 RES-CHIP 10K 5% 1/10W
R238 1-218-941-11 RES-CHIP 100 5% 1/10W
R239 1-218-973-11 RES-CHIP 47K 5% 1/10W
R240 1-218-990-11 SHORT CHIP 0
R242 1-218-990-11 SHORT CHIP 0
R244 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R245 1-218-965-11 RES-CHIP 10K 5% 1/10W
R247 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R248 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R249 1-218-990-11 SHORT CHIP 0
R250 1-218-990-11 SHORT CHIP 0
R251 1-218-965-11 RES-CHIP 10K 5% 1/10W
R252 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R253 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R254 1-218-990-11 SHORT CHIP 0
R256 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R257 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R258 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R259 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R260 1-218-961-11 RES-CHIP 4.7K 5% 1/10W
R261 1-218-990-11 SHORT CHIP 0
MB
Ver 1.2
