Sony HCD-FL5D - Page 53

HCD-FL5D
5353
1.6 Vp-p
50 ns
Approx.
50 mVp-p
Approx.
1.2 Vp-p
Approx.
100 mVp-p
• Waveforms
– RF Board –
1 IC001 1 (DVDRFP)
Approx.
1.2 Vp-p
Approx.
50 mVp-p
Approx.
100 mVp-p
Approx.
400 mVp-p
3 IC001 r; (FE)
4 IC001 tj (RFAC)
2 IC001 el (TE)
Approx.
50 mVp-p
3.4 Vp-p
40.8 µ s
qs IC509 el (FE)
qd IC509 ra (TE)
– MB Board –
qa IC509 0 (WFCK)
qf IC401 t; (RFAC)
3.4 Vp-p
6.8 µ s
qg IC509 yg (LRCK)
qh IC509 yj (BCK)
4.5 Vp-p
142 ns
Approx.
1.2 Vp-p
qj IC509 ua (XTAI)
qk IC701 <zzm (RFIN)
ql IC701 <zbz (WFCK)
3.4 Vp-p
40.8 µ s
4.5 Vp-p
142 ns
w; IC701 <zb, (BCLK)
4.5 Vp-p
29.5 ns
wa IC701 <znc (LRCK)
3.4 Vp-p
6.8 µ s
ws IC701 <znm (XTAL)
4.7 Vp-p
29.5 ns
Approx.
100 mVp-p
wf IC901 yg (TE)
wg IC901 yj (FE)
wd IC901 ra (EXTAL)
wh IC906 3 (MO1)
3.8 Vp-p
37 ns
wj IC906 8 (XTO)
4.2 Vp-p
37 ns
750 mVp-p
H
680 mVp-p
H
710 mVp-p
H
1.1 Vp-p
H
wl IC206 <zxx (VDAC 3) (NTSC Color Bars Play)
e; IC206 <zxb (VDAC 2) (NTSC Color Bars Play)
wk IC206 <zz. (VDAC 4) (NTSC Color Bars Play)
ea IC206 <zx, (VDAC 1) (NTSC Color Bars Play)
1.2 Vp-p
H
es IC206 <zcz (VDAC 0) (NTSC Color Bars Play)
ed IC206 <zc. (XIN)
4.3 Vp-p
37 ns
