Sony HCD-FL5D - Page 69

HCD-FL5D
6969
ys IC601 qf (SCKOUT)ts IC101 qd (X-OUT)
2.1 Vp-p
12.1 µ s
10.8Vp-p
12.1 µ s
rs Q4, Q5 (Collector) (REC Mode)
0.4 Vp-p
12.1 µ s
rd Q4, Q5 (Emitter) (REC Mode)
ta IC101 qa (XC-OUT)
– MC Board –
2.6 Vp-p
30.6
µ s
1.9 Vp-p
62.8
µ s
ya IC601 qs (MCLK2)
– DSP Board –
3.8 Vp-p
74
µ s
3.5 Vp-p
82 ns
yf IC601 w; (BCK0)
yd IC601 w; (LRCK0)
yg IC611 qd (LRCK)
yh IC611 qf (BCK)
yj IC611 qh (SYSCK)
yk IC603 wk (XOUT)
ua IC201 id (XO)
– GC Board –
3.4 Vp-p
20.8
µ s
3.3 Vp-p
326 ns
3.5 Vp-p
20.8
µ s
3.2 Vp-p
326 ns
3.5 Vp-p
82 ns
3.6 Vp-p
81
µ s
3.4 Vp-p
250 ns
• Waveforms
– SP RELAY Board –
ra Q4, Q5 (Base) (REC Mode)
is IC701 wa, ws (CB OUT)
(NTSC Color Bars Play)
– VIDEO Board –
id IC701 wf, wg (CY OUT), wj, wk (Y OUT)
(NTSC Color Bars Play)
if IC701 e;, ea (V OUT)
(NTSC Color Bars Play)
ig IC701 ed(C OUT)
(NTSC Color Bars Play)
ia IC701 qk, ql (CR OUT)
(NTSC Color Bars Play)
1.4 Vp-p
H
1.4 Vp-p
H
2 Vp-p
H
2 Vp-p
H
1.2 Vp-p
H
