117
HCD-FL7D
Pin No. Pin Name I/O Description
86 PB-A/B O
Deck-A/B selection signal output “L”: deck-B, “H”: deck-A
87 EQ-H/N O
Normal/high speed selection signal output “L”: normal speed, “H”: high speed
88 ALC O
Automatic limiter control signal output “H”: limiter on
89 DIR-RST O
Reset signal output to the digital audio interface receiver
90 S/W O
SW phase control signal output terminal
91 A-SHUT I
Shut off detection signal input from the deck-A side reel pulse detector
92 B-SHUT I
Shut off detection signal input from the deck-B side reel pulse detector
93 B-HALF I
Deck-B cassette detection signal input terminal “L”: cassette in, “H”: no cassette
94 MODEL-IN I
Model setting terminal
95 SPEC-IN I
Destination setting terminal
96
AVSS — Ground terminal
97 AMS-IN I
Automatic music sensor detection signal input
98
VREF
I
Reference voltage (+3.3V) input terminal
99 AVCC —
Power supply terminal (+3.3V)
100 AC-CUT I
AC cut on/off detection signal input from the reset signal generator
“L”: AC cut on, “H”: AC cut off or checked
