Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
158
HCD-FL7D
MIC OUT/MIDOUT SW PANEL (L) PANEL (R)
R360 1-216-833-11 RES-CHIP 10K 5% 1/10W
R361 1-216-833-11 RES-CHIP 10K 5% 1/10W
R362 1-216-821-11 RES-CHIP 1K 5% 1/10W
R363 1-216-845-11 RES-CHIP 100K 5% 1/10W
R364 1-216-864-11 SHORT CHIP 0
R365 1-216-835-11 RES-CHIP 15K 5% 1/10W
(EA, SP, KR)
R366 1-216-835-11 RES-CHIP 15K 5% 1/10W
(EA, SP, KR)
R367 1-216-837-11 RES-CHIP 22K 5% 1/10W
(EA, SP, KR)
R368 1-216-837-11 RES-CHIP 22K 5% 1/10W
(EA, SP, KR)
R369 1-216-841-11 RES-CHIP 47K 5% 1/10W
(EA, SP, KR)
R370 1-216-837-11 RES-CHIP 22K 5% 1/10W
(EA, SP, KR)
R371 1-216-837-11 RES-CHIP 22K 5% 1/10W
(EA, SP, KR)
R372 1-216-837-11 RES-CHIP 22K 5% 1/10W
(EA, SP, KR)
R373 1-216-846-11 RES-CHIP 120K 5% 1/10W
(EA, SP, KR)
R374 1-216-814-11 RES-CHIP 270 5% 1/10W
(EA, SP, KR)
R375 1-216-837-11 RES-CHIP 22K 5% 1/10W
(EA, SP, KR)
< VARIABLE RESISTOR >
RV351 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV352 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
(EA, SP, KR)
**************************************************************
1-683-898-11 OUT/MIDOUT SW BOARD
********************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MIDOUT)
S702 1-771-218-11 SWITCH, MICRO (LID)
S708 1-771-218-11 SWITCH, MICRO (OUT)
**************************************************************
A-4676-820-A PANEL (L) BOARD, COMPLETE (US, CND)
A-4728-401-A PANEL (L) BOARD, COMPLETE
(EA, MX, SP, KR)
A-4731-210-A PANEL (L) BOARD, COMPLETE (AEP, UK)
*************************
< CAPACITOR >
C301 1-126-947-11 ELECT 47uF 20% 10V
< LED >
D301 8-719-058-04 LED SEL5223S-TP15 (\/1)
(EXCEPT AEP, UK)
D301 8-719-077-44 LED SELS5223C-TP15 (\/1) (AEP, UK)
D302 8-719-071-41 LED SELS5923C-TP15 (DVD)
D303 8-719-071-41 LED SELS5923C-TP15 (TUNER/BAND)
D304 8-719-071-41 LED SELS5923C-TP15 (TAPE A/B)
< IC >
IC301 6-600-071-01 IC TSOP7000
< RESISTOR >
R301 1-216-813-11 RES-CHIP 220 5% 1/10W
(EXCEPT AEP, UK)
R301 1-216-821-11 RES-CHIP 1K 5% 1/10W
(AEP, UK)
R302 1-216-809-11 RES-CHIP 100 5% 1/10W
R303 1-216-809-11 RES-CHIP 100 5% 1/10W
R304 1-216-809-11 RES-CHIP 100 5% 1/10W
R305 1-216-819-11 RES-CHIP 680 5% 1/10W
R306 1-216-821-11 RES-CHIP 1K 5% 1/10W
R307 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R308 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R309 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R310 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
(US, CND, AEP, UK)
R311 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
(US, CND, AEP, UK)
R312 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
(US, CND, AEP, UK)
R313 1-216-805-11 RES-CHIP 47 5% 1/10W
R314 1-216-805-11 RES-CHIP 47 5% 1/10W
R317 1-216-864-11 SHORT CHIP 0
R318 1-216-864-11 SHORT CHIP 0
R319 1-216-864-11 SHORT CHIP 0
R320 1-216-864-11 SHORT CHIP 0
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (\/1)
S302 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S303 1-771-410-21 SWITCH, TACTILE (DVD)
S304 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S305 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S306 1-771-410-21 SWITCH, TACTILE (DIGITAL)
S307 1-771-410-21 SWITCH, TACTILE (MD (VIDEO))
(EXCEPT US, CND)
S307 1-771-410-21 SWITCH, TACTILE (VIDEO (MD)) (US, CND)
S308 1-771-410-21 SWITCH, TACTILE (GROOVE)
(US, CND, AEP, UK)
S309 1-771-410-21 SWITCH, TACTILE (EFFECT)
(US, CND, AEP, UK)
S310 1-771-410-21 SWITCH, TACTILE (2.1CH/MULTI)
(US, CND, AEP, UK)
**************************************************************
A-4728-403-A PANEL (R) BOARD, COMPLETE
****************
< CAPACITOR >
C313 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-815-603-11 JACK (PHONES)
