Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
159
HCD-FL7D
< RESISTOR >
R321 1-216-819-11 RES-CHIP 680 5% 1/10W
R322 1-216-821-11 RES-CHIP 1K 5% 1/10W
R323 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R324 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R325 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R326 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
R327 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R328 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R329 1-216-819-11 RES-CHIP 680 5% 1/10W
R330 1-216-821-11 RES-CHIP 1K 5% 1/10W
R331 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R332 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
< SWITCH >
S311 1-771-410-21 SWITCH, TACTILE (DISC SELECT)
S312 1-771-410-21 SWITCH, TACTILE (Z)
S313 1-771-410-21 SWITCH, TACTILE (gG)
S314 1-771-410-21 SWITCH, TACTILE (X)
S315 1-771-410-21 SWITCH, TACTILE (x)
S316 1-771-410-21 SWITCH, TACTILE (.)
S317 1-771-410-21 SWITCH, TACTILE (>)
S318 1-771-410-21 SWITCH, TACTILE (– m)
S319 1-771-410-21 SWITCH, TACTILE (M +)
S320 1-771-410-21 SWITCH, TACTILE (DVD TOP MENU)
S321 1-771-410-21 SWITCH, TACTILE (DVD MENU)
S322 1-771-410-21 SWITCH, TACTILE (CD SYNC, HI-DUB)
S323 1-771-410-21 SWITCH, TACTILE (REC, PAUSE/START)
S324 1-771-410-21 SWITCH, TACTILE (Z B)
**************************************************************
1-684-271-11 REGULATOR BOARD
****************
< CAPACITOR >
C870 1-115-867-11 ELECT 0.1uF 20% 50V
C871 1-115-867-11 ELECT 0.1uF 20% 50V
C872 1-115-867-11 ELECT 0.1uF 20% 50V
C873 1-115-867-11 ELECT 0.1uF 20% 50V
C878 1-126-791-11 ELECT 10uF 20% 16V
C879 1-126-791-11 ELECT 10uF 20% 16V
C880 1-126-791-11 ELECT 10uF 20% 16V
C881 1-126-791-11 ELECT 10uF 20% 16V
< IC >
IC801 6-701-760-01 IC uPC3504AHF
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-57 IC TA7810S
IC804 8-759-231-53 IC TA7805S
< TRANSISTOR >
Q864 8-729-030-19 TRANSISTOR 2SB1640 (TP)
Q865 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R871 1-216-826-11 RES-CHIP 2.7K 5% 1/10W
R872 1-216-826-11 RES-CHIP 2.7K 5% 1/10W
R873 1-216-826-11 RES-CHIP 2.7K 5% 1/10W
R887 1-216-809-11 RES-CHIP 100 5% 1/10W
**************************************************************
A-4728-690-A RF BOARD, COMPLETE
******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C037 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
PANEL (R) REGULATOR RF
