Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
164
HCD-FL7D
R883 1-260-304-51 CARBON 10 5% 1/2W
(KR)
0R885 1-215-861-00 METAL OXIDE 47 5% 1W F
0R886 1-215-861-00 METAL OXIDE 47 5% 1W F
R889 1-216-833-11 RES-CHIP 10K 5% 1/10W
R890 1-216-820-11 RES-CHIP 820 5% 1/10W
R891 1-216-805-11 RES-CHIP 47 5% 1/10W
< VARIABLE RESISTOR >
RV2 1-241-768-11 RES, ADJ, CARBON 220K
RV52 1-241-768-11 RES, ADJ, CARBON 220K
RV53 1-238-019-11 RES, ADJ, CARBON 47K
< RELAY >
RY801 1-515-921-11 RELAY
RY802 1-515-921-11 RELAY (EA, MX, SP, KR)
RY803 1-515-921-11 RELAY (EA, MX, SP, KR)
RY804 1-515-833-11 RELAY
RY805 1-515-833-11 RELAY
RY806 1-515-833-11 RELAY (EA, MX, SP, KR)
RY807 1-515-921-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM801 1-694-656-21 TERMINAL BOARD (6CH SPEAKER)
(SPEAKER)
**************************************************************
A-4676-819-A SUB TRANS BOARD, COMPLETE (US, CND)
A-4676-840-A SUB TRANS BOARD, COMPLETE (AEP, UK)
A-4730-192-A SUB TRANS BOARD, COMPLETE (SP)
A-4730-194-A SUB TRANS BOARD, COMPLETE (KR)
A-4730-197-A SUB TRANS BOARD, COMPLETE (MX)
A-4730-199-A SUB TRANS BOARD, COMPLETE (EA)
****************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C901 1-104-665-11 ELECT 100uF 20% 10V
C902 1-126-767-11 ELECT 1000uF 20% 16V
(US, CND)
C902 1-126-935-11 ELECT 470uF 20% 16V
(EXCEPT US, CND)
C903 1-164-159-11 CERAMIC 0.1uF 50V
C905 1-126-964-11 ELECT 10uF 20% 50V
C906 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
(EXCEPT EA, SP)
CN902 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(EA, SP)
CN903 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D901 8-719-083-89 DIODE 11ES2N-TB5
D902 8-719-083-89 DIODE 11ES2N-TB5
D903 8-719-083-89 DIODE 11ES2N-TB5
D904 8-719-083-89 DIODE 11ES2N-TB5
D905 8-719-911-19 DIODE 1SS133T-72
D906 8-719-911-19 DIODE 1SS133T-72
< IC >
IC901 8-759-647-10 IC uPC2933HF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-467-21 RELAY (POWER)
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(EA, SP)
< TRANSFORMER >
0T901 1-437-675-11 TRANSFORMER, POWER (US, CND)
0T901 1-437-676-11 TRANSFORMER, POWER (AEP, UK)
0T901 1-437-677-11 TRANSFORMER, POWER (EA, MX, SP, KR)
**************************************************************
A-4676-533-A SW BOARD, COMPLETE
**********
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< PHOTO INTERRUPTER >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R1001 1-249-406-11 CARBON 120 5% 1/4W
R1002 1-249-406-11 CARBON 120 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
SP RELAY SUB TRANS SW
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
