Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
165
HCD-FL7D
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLEY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLEY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1005 1-771-536-12 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1009 1-771-536-12 SWITCH, LEAF (DECK B REC)
**************************************************************
1-684-198-11 TC DOOR BOARD
**************
< CONNECTOR >
CN319 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D309 8-719-988-61 DIODE 1SS355TE-17
D310 8-719-988-61 DIODE 1SS355TE-17
< SHORT >
JR214 1-216-864-11 SHORT CHIP 0
**************************************************************
1-684-199-11 TC DOOR SW BOARD
*****************
< SWITCH >
S325 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY)
(CASSETTE LID OPEN/CLOSE DETECT)
**************************************************************
1-684-200-11 TC SW (A) BOARD
***************
< RESISTOR >
R338 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
< SWITCH >
S326 1-771-410-21 SWITCH, TACTILE (A Z)
**************************************************************
A-4676-812-A TRANS BOARD, COMPLETE (US, CND)
A-4676-835-A TRANS BOARD, COMPLETE (AEP, UK)
A-4730-184-A TRANS BOARD, COMPLETE (SP)
A-4730-186-A TRANS BOARD, COMPLETE (KR)
A-4730-188-A TRANS BOARD, COMPLETE (MX)
A-4730-190-A TRANS BOARD, COMPLETE (EA)
*************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C913 1-128-576-11 ELECT 100uF 20% 63V
C914 1-126-960-11 ELECT 1uF 20% 50V
C915 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
* CN914 1-564-522-11 PLUG, CONNECTOR 7P
CN915 1-564-521-11 PLUG, CONNECTOR 6P
* CN916 1-564-523-11 PLUG, CONNECTOR 8P
< DIODE >
D911 8-719-083-89 DIODE 11ES2N-TB5
D912 8-719-983-96 DIODE MTZJ-T-72-39A
D913 8-719-160-29 DIODE RD6.2F-T7B2
D914 8-719-109-68 DIODE MTZJ-T-72-3.6A
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
< RESISTOR >
R911 1-219-237-91 SOLID 3.3M 20% 1/2W
(US, CND)
0R913 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
R914 1-249-417-11 CARBON 1K 5% 1/4W
R915 1-249-429-11 CARBON 10K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
1-684-692-11 VIDEO BOARD
************
< CAPACITOR >
C701 1-104-665-11 ELECT 100uF 20% 10V
C702 1-164-159-11 CERAMIC 0.1uF 50V
C703 1-126-965-11 ELECT 22uF 20% 50V
C704 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-164-159-11 CERAMIC 0.1uF 50V
C742 1-126-935-11 ELECT 470uF 20% 16V
C743 1-104-665-11 ELECT 100uF 20% 25V
C744 1-126-935-11 ELECT 470uF 20% 16V
C745 1-104-665-11 ELECT 100uF 20% 25V
C746 1-126-935-11 ELECT 470uF 20% 16V
C747 1-104-665-11 ELECT 100uF 20% 25V
C748 1-104-665-11 ELECT 100uF 20% 25V
C749 1-126-965-11 ELECT 22uF 20% 50V
C750 1-104-665-11 ELECT 100uF 20% 25V
C751 1-126-965-11 ELECT 22uF 20% 50V
SW TC DOOR TC DOOR SW TC SW (A) TRANS VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
