Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
166
HCD-FL7D
C761 1-126-960-11 ELECT 1uF 20% 50V
C762 1-126-960-11 ELECT 1uF 20% 50V
C763 1-126-960-11 ELECT 1uF 20% 50V
C764 1-126-960-11 ELECT 1uF 20% 50V
C765 1-126-960-11 ELECT 1uF 20% 50V
C766 1-126-960-11 ELECT 1uF 20% 50V
C780 1-162-207-31 CERAMIC 22PF 5% 50V
C781 1-162-207-31 CERAMIC 22PF 5% 50V
C782 1-162-207-31 CERAMIC 22PF 5% 50V
C784 1-162-207-31 CERAMIC 22PF 5% 50V
C785 1-162-207-31 CERAMIC 22PF 5% 50V
C786 1-162-207-31 CERAMIC 22PF 5% 50V
< CONNECTOR >
CN701 1-816-590-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
< IC >
IC701 6-702-335-01 IC MM1568
< JACK >
J701 1-793-445-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J702 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J703 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L701 1-410-470-11 INDUCTOR 10uH
< TRANSISTOR >
Q711 8-729-422-57 TRANSISTOR BN1A4M-TP
Q712 8-729-900-89 TRANSISTOR BA1L4M-TP
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-429-11 CARBON 10K 5% 1/4W
R717 1-247-804-11 CARBON 75 5% 1/4W
R718 1-247-804-11 CARBON 75 5% 1/4W
R719 1-247-804-11 CARBON 75 5% 1/4W
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-804-11 CARBON 75 5% 1/4W
R724 1-249-429-11 CARBON 10K 5% 1/4W
R725 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MISCELLANEOUS
**************
53 1-773-044-11 WIRE (FLAT TYPE) (17 CORE)
110 1-773-032-11 WIRE (FLAT TYPE) (15 CORE)
158 1-823-861-11 WIRE (FLAT TYPE) (8 CORE)
301 1-782-252-11 WIRE (FLAT TYPE) (9 CORE)
302 1-824-686-11 WIRE (FLAT TYPE) (13 CORE)
303 1-773-123-11 WIRE (FLAT TYPE) (19 CORE)
304 1-469-829-11 CORE, FERRITE (US, CND, AEP, UK, KR)
308 1-773-049-11 WIRE (FLAT TYPE) (17 CORE)
310 1-824-652-11 WIRE (FLAT TYPE) (29 CORE)
311 1-773-105-11 WIRE (FLAT TYPE) (19 CORE)
312 1-769-937-11 WIER (FLAT TYPE) (11 CORE)
352 1-792-099-11 WIRE (FLAT TYPE) (17 CORE)
353 1-590-218-11 WIRE (FLAT TYPE) (11 CORE)
(EXCEPT AEP, UK)
353 1-773-012-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
358 1-693-570-21 TUNER (FM/AM) (AEP, UK)
358 1-693-571-11 TUNER (KR)
358 1-693-572-21 TUNER (FM/AM) (EA, MX, SP)
358 1-693-573-21 TUNER (FM/AM) (US, CND)
0453 1-569-008-21 ADAPTOR, CONVERSION (EA, SP)
0453 1-770-019-51 ADAPTOR, CONVERSION PLUG (UK)
0455 1-769-079-22 CORD, POWER (KR)
0455 1-777-071-83 CORD, POWER (AEP, UK, EA, SP)
0455 1-783-531-32 CORD, POWER (US, CND)
0455 1-791-901-21 CORD, POWER (MX)
0703 A-4678-461-A OPTICAL TRAVERSE UNIT
(SERVICE ASSY, DBU-1)
705 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
0F913 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A/125V) (US)
0F913 1-576-193-21 FUSE, GLASS TUBE (DIA. 5) (6.3A/125V)
(CND)
0F913 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
(EA, MX, SP)
0F913 1-533-470-11 FUSE, GLASS TUBE (DIA. 3.15) (3.15A/250V)
(AEP, UK)
0F914 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A/125V)
(US, CND)
0F914 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
(EXCEPT US, CND)
0F915 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A/125V)
(US, CND)
0F915 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
(EXCEPT US, CND)
0F916 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0F917 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0F918 1-576-537-11 FUSE, GLASS TUBE (DIA. 5) (8A/125V)
(US, CND)
0F918 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (6.3A/250V)
(EXCEPT US, CND)
0F919 1-533-454-11 FUSE, GLASS TUBE (DIA. 5) (6.3A/125V)
(US, CND)
0F919 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
(EXCEPT US, CND)
HP901 X-4953-985-1 BLOCK (A) ASSY, HEAD (PB)
HRPE901X-4953-986-1 BLOCK (B) ASSY, HEAD (REC/PB/ERASE)
IC801 6-701-760-01 IC UPC3504AHF
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-57 IC TA7810S
