Sony MHC-V41D Service Manual

MHC-V41D
14
2-6. LOADING PANEL
4 spring (LP)
8 base loading
0 loading panel
7 loading cushion
(See Fig. D)
2 hemilon cushion
(See Fig. B)
hemilon cushion
hemilon cushion
hemilon
cushion
3DVWLQJSRVLWLRQRIWKHORDGLQJFXVKLRQ
front side
front side
rear side
rear side
bottom side
front side
top side
front side
rear side
loading cushion
guide line
guide line
guide line
guide line
)LJ'!
3DVWLQJSRVLWLRQRIWKHKHPLORQFXVKLRQ
)LJ%!
)LJ&!
OK NG
5 claw
5 claw
9 hemilon cushion
(See Fig. C)
9 hemilon cushion
(See Fig. C)
6 Remove the base loading
block in the direction of
the arrow.
3 Draw the spring (LP)
out of the two holes.
1RWHDERXWLQVWDOOLQJWKHVSULQJ/3
–%RWWRPYLHZ–
–%RWWRPYLHZ–
–%RWWRPYLHZ–
–,QQHUYLHZ–
–)URQWYLHZ–
base loading
loading panel block
loading panel
The spring loading has good balance.
(the center of the spring is centered)
spring (LP)
The spring loading has poor balance.
(the center of the spring is shifted to
the left or right)
1 hemilon
(See Fig. E)
1 hemilon
(See Fig. E)
)LJ(!
3DVWLQJSRVLWLRQRIWKHKHPLORQ
hemilon
hemilon
spring (LP)
front side
rear side
front side
rear side
–%RWWRPYLHZ–
guide line
Bend.
Bend.
loading panel block

Sony MHC-V41D Specifications

General

Cassette deck	No
Product color	Black
Number of decks	1 deck(s)
Disc loading type	Tray
Optical disc player	Yes
Number of optical discs	1 discs
Coloration	Monochromatic
Bluetooth profiles	A2DP, AVRCP, SPP
Illumination location	Front
Number of microphone inputs	2
Audio decoders	Dolby Digital
RMS rated power	- W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	1
Mid-range driver diameter	80 mm
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-RW
Playback disc formats	DVD-Video, VCD
Audio formats supported	MP3
Video formats supported	MPEG4, XVID
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	20
Power source	AC
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth	308 mm
Width	328 mm
Height	796 mm
Weight	13500 g
