68
MHC-V41D
SECTION 8
ELECTRICAL PARTS LIST
GESTURE BOARD
**************
< CONNECTOR >
CN7500 1-785-466-41 CONNECTOR, FFC/FPC 7P
< DIODE >
D7500 6-500-400-01 DIODE BAV99-215
D7501 6-500-400-01 DIODE BAV99-215
D7502 6-500-400-01 DIODE BAV99-215
D7503 6-500-400-01 DIODE BAV99-215
* D7504 6-503-578-01 DIODE RB520SM-30T2R
* D7505 6-503-578-01 DIODE RB520SM-30T2R
* D7506 6-503-578-01 DIODE RB520SM-30T2R
* D7507 6-503-578-01 DIODE RB520SM-30T2R
< IC >
IC7500 6-722-772-01 IC MGC3030
*************************************************************
IR BOARD
********
< IC >
IC7450 6-600-768-01 IC PNA4823M03S0 ( )
*************************************************************
A-2192-236-A MIC BOARD, COMPLETE
*******************
< CONNECTOR >
CN7701 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D7704 6-500-400-01 DIODE BAV99-215
D7705 6-500-400-01 DIODE BAV99-215
< FERRITE BEAD >
FB7700 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB7701 1-414-813-11 FERRITE, EMI (SMD) (2012)
< IC >
IC7700 8-759-909-71 IC BA4558F
< JACK >
J7700 1-822-967-12 JACK (MIC 1)
J7701 1-822-967-12 JACK (MIC 2 GUITAR)
< JUMPER RESISTOR >
JR7701 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q7707 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q7708 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
*************************************************************
9 A-2201-879-A MOTHER BOARD, COMPLETE (SV) (See Note 1)
***********************
< IC >
IC001 6-721-079-01 IC TPS542941PWPR
IC002 6-722-439-01 IC BDJ2FC0WEFJ-E2
IC004 6-721-872-01 IC 78D09AG-TN3-R
IC006 6-721-766-01 IC 78D05AG-TN3-R
IC008 6-722-001-01 IC 78D12AG-TN3-R
IC009 6-721-079-01 IC TPS542941PWPR
IC305 6-719-198-01 IC MM3411A33URE
IC1000 6-718-999-01 IC MM1839A50NRE
IC2001 6-723-247-01 IC TAS5534DGGR-S
IC2002 6-723-793-01 IC TAS5634 (See Note 2)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, replace the CDM90 ASSY (Ref. No. CDM1).
*************************************************************
A-2194-756-A NFC BOARD, COMPLETE (See Note 3)
********************
When the NFC board is defective, replace the complete mounted board.
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
Due to standardization, replacements in
the parts list may be different from the
parts speci ed in the diagrams or the com-
ponents used on the set.
-XX and -X mean standardized parts, so
they may have some difference from the
original one.
Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal- lm resistor.
METAL OXIDE: Metal oxide- lm resistor.
F: non ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number speci ed.
The components identi ed by mark 9 con-
tain con dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Among mounted electrical parts on each
board, only parts that are described in the
electrical parts list can be replaced for re-
pairing.
The parts that are not described in the
electrical parts list cannot be replaced with
single for repairing.
Note 1: When the MOTHER board is replaced, be sure to refer
to “DESTINATION SETTING METHOD” and “NFC
OPERATION CHECKING METHOD” on page 6.
Note 3: When the NFC board is replaced, be sure to refer to “NFC
OPERATION CHECKING METHOD” on page 6.
Note 2: When the IC2002 on the MOTHER board is replaced,
refer to “SPREADING OF COMPOUND” on page 7.
GESTURE IR MIC
MOTHER MS-476 NFC
