Sony MHC-V41D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V41D
6969
A-2192-235-A PANEL BOARD, COMPLETE (LA)
A-2218-978-A PANEL BOARD, COMPLETE (AEP, UK, AUS)
*********************
< CONNECTOR >
CN7801 1-819-866-11 USB CONNECTOR (A) (
REC/PLAY 5V 1A)
< DIODE >
D7000 6-504-215-11 LED HL-364V620MZ-JS (MEGA BASS)
D7002 6-504-214-21 LED HL-3TMH234WW-3.7-HK-BF-SN-J
(GESTURE ON/OFF)
D7003 6-504-213-11 LED HL-364B460MZ-JS
( PAIRING BLUETOOTH)
D7005 6-503-605-01 DIODE UDZVTE-172.0B
D7800 6-502-970-01 DIODE DZ2J068M0L
D7801 6-500-400-01 DIODE BAV99-215
D7802 6-500-400-01 DIODE BAV99-215
D7803 6-500-400-01 DIODE BAV99-215
< IC >
IC7000 6-719-142-01 IC TC62D723FNG
< JUMPER RESISTOR >
JR7800 1-216-296-11 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
ND7000 1-483-549-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q7002 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
< SWITCH >
S7000 1-762-875-21 SWITCH, KEYBOARD (
1
)
S7001 1-762-875-21 SWITCH, KEYBOARD (x)
S7002 1-762-875-21 SWITCH, KEYBOARD (N)
S7003 1-762-875-21 SWITCH, KEYBOARD ( )
S7004 1-762-875-21 SWITCH, KEYBOARD (KARAOKE)
S7005 1-762-875-21 SWITCH, KEYBOARD ( PAIRING BLUETOOTH)
S7006 1-762-875-21 SWITCH, KEYBOARD (– VOLUME)
S7007 1-762-875-21 SWITCH, KEYBOARD (MEGA BASS)
S7008 1-762-875-21 SWITCH, KEYBOARD (– )
S7009 1-762-875-21 SWITCH, KEYBOARD (PARTY CHAIN)
S7010 1-762-875-21 SWITCH, KEYBOARD (MIC/GUITAR LEVEL –)
S7011 1-762-875-21 SWITCH, KEYBOARD (PARTY LIGHT)
S7012 1-762-875-21 SWITCH, KEYBOARD (VOCAL FADER)
S7013 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD)
S7014 1-762-875-21 SWITCH, KEYBOARD (VOICE CHANGER)
S7015 1-762-875-21 SWITCH, KEYBOARD (FIESTA)
S7016 1-762-875-21 SWITCH, KEYBOARD (MIC ECHO)
S7017 1-762-875-21 SWITCH, KEYBOARD (W.PARTY CHAIN)
S7018 1-762-875-21 SWITCH, KEYBOARD (GUITAR)
S7019 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S7020 1-762-875-21 SWITCH, KEYBOARD (MIC/GUITAR LEVEL +)
S7021 1-762-875-21 SWITCH, KEYBOARD (
+)
S7022 1-762-875-21 SWITCH, KEYBOARD (GESTURE ON/OFF)
S7023 1-762-875-21 SWITCH, KEYBOARD (VOLUME +)
S7024 1-762-875-21 SWITCH, KEYBOARD (PLAYBACK)
S7025 1-762-875-21 SWITCH, KEYBOARD (Z)
S7026 1-762-875-21 SWITCH, KEYBOARD (DJ)
S7027 1-762-875-21 SWITCH, KEYBOARD (TUNING + >)
S7028 1-762-875-21 SWITCH, KEYBOARD (SAMPLER)
S7029 1-762-875-21 SWITCH, KEYBOARD (– TUNING .)
*************************************************************
A-2192-239-A PARTY LED BOARD, COMPLETE
*************************
When the PARTY LED board is defective, replace the complete mounted board.
*************************************************************
A-2203-074-A SMPS BOARD, COMPLETE (LA)
A-2218-781-A SMPS BOARD, COMPLETE (AEP, UK, AUS)
*********************
When the SMPS board is defective, replace the complete mounted board.
*************************************************************
A-2192-240-A SW LED BOARD, COMPLETE
***********************
When the SW LED board is defective, replace the complete mounted board.
*************************************************************
MISCELLANEOUS
**************
CDM1 A-1937-669-C CDM90 ASSY (Including MS-476 board)
FFC1 1-972-245-11 FLEXIBLE FLAT CABLE (24P) (L = 200 mm)
FFC2 1-972-243-11 FLEXIBLE FLAT CABLE (5P) (L = 230 mm)
FFC3 1-972-242-11 FLEXIBLE FLAT CABLE (7P) (L = 260 mm)
FFC4 1-972-241-11 FLEXIBLE FLAT CABLE (19P) (L = 270 mm)
FFC5 1-972-246-11 FLEXIBLE FLAT CABLE (6P) (L = 210 mm)
FFC6 1-972-244-11 FLEXIBLE FLAT CABLE (7P) (L = 240 mm)
0 M1 1-855-006-41 FAN, DC
MIC1 1-852-158-11 MICROPHONE, ELECTRET CAP
0 OP1 A-2046-956-A OPTICAL PICK-UP BLOCK (CMS-S76RFS7G) (SV)
(Including Sled motor, Spindle motor, Sheet)
SP1 1-859-278-11 LOUDSPEAKER (69 mm) (Midrange: L-ch)
SP2 1-859-277-11 LOUDSPEAKER (34 mm) (Tweeter: L-ch)
SP3 1-859-278-11 LOUDSPEAKER (69 mm) (Midrange: R-ch)
SP4 1-859-277-11 LOUDSPEAKER (34 mm) (Tweeter: R-ch)
SP5 1-859-276-11 LOUDSPEAKER (260 mm) (Subwoofer)
*************************************************************
ACCESSORIES
************
4-729-484-13 MANUAL, INSTRUCTION (Operating Instructions)
(ENGLISH) (UK, AUS, LA)
4-729-484-23 MANUAL, INSTRUCTION (Operating Instructions)
(SPANISH) (LA)
4-729-484-32 MANUAL, INSTRUCTION (Operating Instructions)
(FRENCH) (AEP)
4-729-484-42 MANUAL, INSTRUCTION (Operating Instructions)
(GERMAN) (AEP)
4-729-484-52 MANUAL, INSTRUCTION (Operating Instructions)
(DUTCH) (AEP)
4-729-484-62 MANUAL, INSTRUCTION (Operating Instructions)
(ITALIAN) (AEP)
4-729-484-72 MANUAL, INSTRUCTION (Operating Instructions)
(POLISH) (AEP)
4-729-485-62 MANUAL, INSTRUCTION (Operating Instructions)
(SPANISH) (AEP)
PANEL PARTY LED SMPS SW LED

Sony MHC-V41D Specifications

General

Cassette deck	No
Product color	Black
Number of decks	1 deck(s)
Disc loading type	Tray
Optical disc player	Yes
Number of optical discs	1 discs
Coloration	Monochromatic
Bluetooth profiles	A2DP, AVRCP, SPP
Illumination location	Front
Number of microphone inputs	2
Audio decoders	Dolby Digital
RMS rated power	- W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	1
Mid-range driver diameter	80 mm
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-RW
Playback disc formats	DVD-Video, VCD
Audio formats supported	MP3
Video formats supported	MPEG4, XVID
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	20
Power source	AC
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth	308 mm
Width	328 mm
Height	796 mm
Weight	13500 g
