4 SMPS Board Mount Diagnosis Flow
NO6501: pin 9 (MAIN ON)
Standby Demo mode Power on
Low (0 V) Hi (3.3 V) Hi (3.3 V)
NO6501:
pin 1 (A-supply),
pin 4, 5 (M-supply)
Standby Demo mode Power on
17.4 V ± 5 % 17.4 V ± 5 % 17.4 V ± 5 %
CN6500: pin 6 to 9 (V1) 58.5 V ± 5 % 58.5 V ± 5 %
58.5 V ± 5 %
Connect the power supply cord.
The voltage of the following is outputted.
No
Check whether the state of the power
supply cord and AC outlet are normal.
If there are no problems, check the
surrounding circuit for MAIN ON signal
output on the MOTHER board.
Yes
The voltage of the following is outputted.
No No
Check the following 2 points.
)XVHV))KDYHEHHQQRW
opened.
$&SRZHUVXSSO\YROWDJHKDVEHHQ
applied to the varistor (VR6000).
Yes
End
Yes
5HSODFHWKHIXVHV))DQG
varistor (VR6000), and check the voltage
again.
Replace the SMPS board.
