204
Basic Procedure for Wipe Settings
Chapter 5 Wipes
4
When you selected border or soft border, select the edge fill signal in the
<Edge Fill> group.
Utility Bus: signal selected on the utility bus
Matte: signal from the dedicated color matte generator
5
Depending on the operation in step 4, carry out the following operation.
When ‘Utility Bus’ is selected: Press the key delegation [UTIL], and
select the signal in the key row.
When ‘Matte’ is selected: In the same Edge/Direction menu, press [Matte
Adjust] to display the Matte Adjust menu, then adjust the single-color
or two-color combination color matte. Select whether to use a single-
color matte or a two-color combination in the <Edge Matte> group.
Flat Color: Adjust color 1 with the following parameters.
When you select [Mix Color] for a two-color combination, see the next
paragraph.
Carrying out a color mix for the edge fill matte
When you selected [Matte] for the border or soft border edge fill, you can
combine color 1 and color 2.
For the combination, you can use not only a normal wipe generator pattern, but
also the dedicated color mix pattern.
1
In the <Edge Fill> group of the Edge/Direction menu, select [Matte], and
press [Matte Adjust].
The Matte Adjust menu appears.
2
In the <Edge Matte> group, select [Mix Color], turning it on.
3
In the <Mix Pattern> group, make one of the following selections.
Wipe: Use the wipe pattern selected for the transition.
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
2 Inner Soft Border inner softness 0.00 to 100.00
3 Outer Soft Border outer softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
