216
Wipe Settings for Independent Key Transitions
Chapter 5 Wipes
Rotating the wipe pattern (Rotation)
1
In the <Rotation> group of the Key1 Wipe Adjust menu, select the rotation
type.
Angle: Incline the pattern through a fixed angle.
Speed: Rotate at a speed rate.
Magnitude: Rotate the pattern through a fixed angle during the course of
the transition.
2
According to the selection in step 1, set the following parameters.
• When Angle is selected
a) See page 208.
• When Speed is selected
a) See page 209.
• When Magnitude is selected
a) See page 209.
Setting the wipe pattern aspect ratio (Aspect ratio)
1
Press [Aspect] in the Key1 Wipe Adjust menu, turning it on.
2
Set the following parameter.
a) See page 210.
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation at start of
transition
–100.00 to +100.00
a)
2 Magnitude Angle of rotation through course
of transition
–200.00 to +200.00
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
To Next Page
