215Wipe Settings for Independent Key Transitions
Chapter 5 Wipes
The buttons in the device control block are assigned to the wipe position
setting as follows.
Table 1: Buttons and assigned settings
Table 2: Buttons assigned to functions
2
Press one of the buttons in Table 1 above, to select the wipe position to
which the operation applies. Multiple selection is possible.
3
Press the [POS] button, turning Position on.
4
Move the trackball or joystick, to set the wipe position. By pressing the [X]
button, turning it on, you can restrict movement to the horizontal direction,
and by pressing the [Y] button, turning it on, you can restrict movement to
the vertical direction.
To set the wipe position by a menu operation
1
Press [Position] in the Key1 Wipe Adjust menu, turning it on.
2
Set the following parameters.
a) See page 207.
To move the pattern from its current position to the center through
the course of a transition
Press [Auto Center
] in the <Position> group, turning
it on.
Button name Setting
K1 CB1 Wipe position for independent key 1 transition
K2 Wipe position for independent key 2 transition
K3 Wipe position for independent key 3 transition
K4 Wipe position for independent key 4 transition
Button name Function
POS Toggle Position on or off.
X, Y Fix the operating direction.
CTR Return the pattern position to the center of the screen.
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
a)
2 Position V Vertical position
–200.00 to +200.00
a)
