104
Specifications
Appendix
not possible to control such a device from
this unit using AV/C commands.
About the required i.LINK
cable
Use the Sony 6-pin-to-4-pin or 6-pin-to-6-
pin i.LINK cable (for dubbing) to connect
the i.LINK devices.
i.LINK and are trademarks.
Specifications
General
Power requirements
12.0 V DC
Power consumption
12 W
Peak inrush current
(1) Power ON, current probe
method: 12 A (100 V), 34 A
(240 V)
(2) Hot switching inrush
current, measured in
accordance with European
standard EN55103-1: 5.5 A
(230 V)
Operating temperature
5°C to 40°C (41°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to
+140°F)
Mass Unit only: 2.0 kg (4 lb 6 oz)
With AC adaptor and stand: 2.3
kg (5 lb 1 oz)
External dimensions (w/h/d, excluding
projections)
210 × 88 × 200 mm (8
3
/
8
×
3
1
/
2
× 7
7
/
8
inches)
Unit: mm (inches)
200(7
7
/
8
)
88(3
1
/
2
)
210(8
3
/
8
)
