Sony PMW-EX30 - During Playback

33
Video Format and Input/Output Signals
Chapter 2 Preparations
when any other video format setting is
selected.)
• When a signal containing strong jitters
(such as a computer output) is input to the
HDV/DV connector, output video and
audio from the HD/SD SDI OUTPUT
and HDMI connectors may be noisy, or
no signal may be output from those
connectors.
• When “HDMI/CMPNT/SDI Out SEL” is
set to “480P (576P)”, no signal is output
from the HD/SD SDI OUTPUT
connector.
In recording/E-E mode
a) “HDMI/CMPNT/SDI Out SEL” is disabled
and the setting value is fixed to 480i (576i)
when the “i.LINK I/O Select” setting of the
VIDEO SET menu is “DVCAM”.
b) 480i when “Country” of the OTHERS menu is
set to “NTSC Area”, or 576i when “Country”
of the OTHERS menu is set to “PAL Area”.
c) This setting allows no signal to be output from
the HD/SD SDI OUTPUT connector.
d) This format allows no signal to be output from
the HDMI connector.
During playback
Formats indicated in parentheses are the
formats of video output during simplified
playback, that is, playback of PAL-format
recorded clips with this unit set to a NTSC
video format or playback of NTSC-format
recorded clips with this unit set to a PAL
video format. During simplified playback,
HD signals are output only from the
COMPONENT connectors.
“Video Format”
setting
Output video format
“HDMI/CMPNT/SDI Out SEL” setting
a)
1080i/720P 1080i
480i (576i)
b)
480P (576P)
b) c)
NTSC HQ 1080/60i
SP 1080/60i
1080/59.94i 480/59.94i 480/59.94P
HQ 1080/30P 1080/29.97PsF
HQ 1080/24P 1080/
23.98PsF
d)
1080/59.94i
HQ 720/60P 720/59.94P 1080/59.94i
PAL HQ 1080/50i
SP 1080/50i
1080/50i 576/50i 576/50P
HQ 1080/25P 1080/25PsF 576/25PsF
HQ 720/50P 720/50P 1080/50i 576/50i
