74
Connecting an External Device with the HD SDI Connector
Chapter 6 Example Connections for Various Applications
To perform dubbing
1 Set the format of video and audio input
signals to HDSDI on the recorder.
For details on the setting, refer to the
operation manual supplied with the recorder.
2 Put the recorder into recording standby
mode.
3 Insert the SxS memory card into this
unit and cue up the clip you want to
dub.
4 Start recording on the recorder.
5 Start playback of the clip on this unit.
6 When dubbing finishes, stop recording
on the recorder and stop playback on
this unit.
Configuring a live
recording system
This section shows an example for
connecting this unit and the BRC-Z700W
HD 3CMOS Color Video Camera,
microphones, AWS-G500 Live Contents
Producer to configure a live recording
system.
On how to connect and use the BRC-Z700W,
microphones and AWS-G500, refer to the operating
instructions supplied with each device.
To Next Page
