Sony PMW-EX30 - Troubleshooting Time Data and Monitor

99
Troubleshooting
Appendix
Time data
External video monitor
Symptoms Cause Remedy
Cannot freely set
the initial time data
value.
Regen mode or Ext
regen mode is
selected.
Set “Mode” in “Timecode” of the TC/UB
SET menu to “Preset” (see page 91).
Symptoms Cause Remedy
Data is not
superimposed on
the monitor screen.
The DISPLAY
button is turned off.
Turn the DISPLAY button on.
Superimposition is
disabled.
Set “HDMI/CMPNT/SDI Out DISP” or
“CMPST/ S Out Display” of the VIDEO
SET menu to “On” (see page 89).
The image on the
monitor screen is
too bright.
The 75 Ω
termination switch
for video input on
the monitor is in the
OFF position, or a
75 Ω terminator is
not fitted to its video
input connector.
Set the 75 Ω termination switch to ON or
connect a terminator.
The image on the
monitor screen is
too dark.
In a video signal
loop-through
connection of
multiple video
monitors, 75 Ω
termination switches
for video input on
monitors other than
the loop-end
monitor are in the
ON position.
Set the 75 Ω termination switches to OFF
on all monitors other than the loop-end
monitor.
