Si Compact Front Panel
Si Compact 24 fader shown:
Si Compact Rear Panel
Si Compact 24 fader shown:
Si Compact Control Surface and Connector Overview
Meters, Monitors
USB & Power
Assignable Channel Strip (ACS)
Colour LCD
Touch Screen
Lexicon FX
Controller
Buss Follow
(tOTEM) Keys
Global Mode
switches and
encoders
Cue Control
Master Faders
and associated
controls
Mute Masters
and Faders
Bank controls
Main Channel or Bus
Master faders, meters
and associated controls
Recallable Mic/Line Inputs x24 (32/16 on other size consoles)
16x Analogue
Line Out
Option card Slot
4x Analogue Inserts
(not 16 fader version)
AES IN & OUT Analogue Line In
Word Clock and
MIDI In & OUT
HiQNet Ethernet Port
Phones socket
under faders
To Next Page
