Si COMPACT OUTPUT PATCHING & LAYERS:
As all Si Compact models offer the same level of output processing and number of physical
outputs, therefore all models have the same Output Layers & Patching system:
• Buses 1-14 > Fader Layer BUS faders 1-14 > Analogue Line Out 1-14
• MTX 1-4 > Fader Layer MTX faders 1-4 > Not Assigned
• Main L&R > Master L&R Fader > Analogue Line Out 15-16
• MONO > MONO/SEL Fader > Not Assigned
NOTE: Any 'unused' faders and associated switches, meters and encoders are unlit and
have no function.
NOTE: Patching can be set or changed from the INPUT or OUTPUT menu as appropriate..
