INPUTS MENU
The INPUTS menu provides information to all parameters and functions concerning system
inputs.
NOTE: The INPUTS button is greyed-out and not accessible unless an input channel is
SELected.
Input Name: The name of the currently SELected input; press the SCROLL/ADJUST
encoder to access the QWERTY keyboard to edit the name.
Type: Sets the channel as either Mono or Linked
NOTE: Channels may be lined as an odd/even pair.
Direct Out Pre/Post: Allows the pick-up point of the direct out to be set as either pre or
post high pass lter.
NOTE: Has no function and is not available unless a Direct Out
patch is active.
Input Patch: Displays the source patched to the channel; see PATCHING for details
of the system patching functionality.
Direct Out Patch: Displays the destination patch of the channel direct out function; see
PATCHING for details of the system patching functionality.
