ST STEVAL-WBC2TX70 User Manual

Item Qty Ref. Value Package Description Manuf. Part number
12 1 C220 1 nF 0402
CAPACITOR SMD 0402 1nF
100V X7R 10%
Wurth 885012205080
13 2
C221,
C222
N.A. 0402
Not populated capacitor SMD
0402
N.A. N.A.
14 1 C228 33 pF 0402
CAPACITOR SMD 0402 33pF
50V C0G 5%
Wurth 885012005058
15 1 C238 1 µF 0402
CAPACITOR SMD 0402 1UF
6.3V X5R 10%
MURATA
GRT155R60J105KE01
D
16 1 C240 2.2 nF 0402
CAPACITOR SMD 0402 2.2nF
50V X7R 5%
MURATA
GCM155R71H222JA37
D
17 2
C303,
C308
100 µF
CAPP_D6.3_PAN
A_D8
100uF Aluminum Electrolytic
Capacitors High temperature
Lead-Free reflow
PANASONIC EEEFTH101XAP
18 2
C407,
C408
100 nF 1812
CAPACITOR SMD 1812 100nF
100V C0G 5%
TDK
C4532C0G2A104J320
KA
19 1 C409 47 nF 1812
CAPACITOR SMD 1812 47nF
100V C0G 5%
TDK
C4532C0G2A473J200
KA
20 1 C412 5.6 nF 0402
CAPACITOR SMD 0402 5.6nF
50V X7R 10%
KEMET C0402C562K5RACTU
21 1 C415 5.6 nF 1206
CAPACITOR SMD 1206 5.6nF
100V X7R 10%
KEMET C1206X562K1RACTU
22 1 C503 220 pF 0402
CAPACITOR SMD 0402
220pnF 50V X7R 10%
Wurth 885012205057
23 1 C506 82 nF 0402
CAPACITOR SMD 0402 82nF
16V X7R 10%
YAGEO CC0402KRX7R7BB823
24 1 C507 8.2 nF 0402
CAPACITOR SMD 0402 8.2nF
50V X7R 10%
KEMET
C0402C822K5RAC786
7
25 1 C508 10 nF 0402
CAPACITOR SMD 0402 10nF
16V X7R 10%
Wurth 885012205031
26 1 D100 SMM4F24A SMB
400 W, 24 V TVS in STmite
Flat
ST SMM4F24A-TR
27 1 D102 ECMF02-2AMX6 DIOD_UQFN-6L
COMMON MODE FILTER
WITH ESD PROTECTION
ST ECMF02-2AMX6
28 1 D103 ESDALC6V1M3 SOT883
VERY LOW CAPACITANCE
LOW LEAKAGE CURRENT
ESD PROTECTION
ST ESDALC6V1M3
29 2
D200,
D201
RB541VM-40 SOD323
SMT Schottky Diode, 40V
200mA, 2-Pin SOD-323
Rohm RB541VM-40TE-17
30 1 D202 RED 0603 LED, 0603, Red
WURTH
ELEKTRONIK
150060RS75000
31 1 D203 GREEN 0603 LED, 0603, Green
WURTH
ELEKTRONIK
150060VS75000
32 3
D204,
D205,
D206
BAT54KFILM SOD523 SMALL SIGNAL_40V_300mA ST BAT54KFILM
33 1 D400 10 V SOD323
VOLTAGE_REGULATOR_0.3
W
NXP OR
OTHERS
BZX384-C10,115
34 1 D500 5 V SOD882 TRANSIL ESD 5V UNI LRC LESD8D5.0AT5G
35 1 D501 LMBR240ET1G SOD323
SMT Schottky Diode, 40V 2A,
2-Pin SOD-323
LRC LMBR240ET1G
36 1 F500 Fan Port
Fan Port, 4 PIN 1mm pitch wire
to board connector
HDGC HDGC1002WR-S-4P
37 1 J100 632723300011
CON_USB_C_63
2723300011
USB TYPE C_632723300011
WURTH
ELEKTRONIK
632723300011
38 1 J101
POWER JACK
DC
CON_JACK_21M
M-PJ-002A
POWER JACK DC
WURTH
ELEKTRONIK
694106301002
UM3286
STEVAL-WBC2TX70 description
UM3286 - Rev 1
page 50/84
