Item
Qty
Ref.
V
alue
Package
Description
Manuf.
Part number
55
2
R206,
R21
1
47 K
0402
NTC SMD 0402 47k 1%
MURA
T
A
NCP15WB473F03RC
56
1
R207
100 K
0402
RESISTOR SMD 100
K_1%_0402_1/16W
Y
AGEO
RC0402FR-07100KL
57
3
R212,
R225,
R226
2.2 R
0402
RESISTOR SMD 2.2
R_5%_0402_1/16W
Y
AGEO
RC0402JR-072R2L
58
2
R213,
R217
470 K
0402
RESISTOR SMD 470
K_5%_0402_1/16W
Y
AGEO
RC0402JR-07470KL
59
1
R218
3.3 K
0402
RESISTOR SMD 3.3
K_1%_0402_1/16W
Y
AGEO
RC0402FR-073K3L
60
2
R227,
R228
4.7 K
0402
RESISTOR SMD 4.7
K_5%_0402_1/16W
Y
AGEO
RC0402JR-074K7L
61
2
R230,
R234
180 K
0402
RESISTOR SMD 180
K_0.1%_0402_1/16W
Y
AGEO
RE0402BRE07180KL
62
1
R231
1.2 K
0402
RESISTOR SMD 1.2
K_0.1%_0402_1/16W
Y
AGEO
RE0402BRE071K2L
63
1
R232
9.1 K
0402
RESISTOR SMD 9.1
K_0.1%_0402_1/16W
Y
AGEO
RE0402BRE079K1L
64
1
R233
5.6 K
0402
RESISTOR SMD 5.6
K_0.1%_0402_1/16W
Y
AGEO
RE0402BRE075K6L
65
1
R235
100 R
0402
RESISTOR SMD 100
R_5%_0402_1/16W
Y
AGEO
RC0402JR-07100RL
66
1
R300
0.010 R
2W
2512
RESISTOR SMD 0.010
R_1%_2512_2W
Wurth
580070763010
67
1
R305
10 R
1206
RESISTOR SMD 10
R_5%_1206_1/4W
Y
AGEO
RC1206JR-0710RL
68
1
R408
0.010 R
0.1%
1W
2512
RESISTOR SMD 0.010
R_0.1%_2512_1W
Vishay Precision
Group Foil
Resistors
Y14870R01000B9R
69
2
R410,
R41
1
30 K
0402
RESISTOR SMD 30
K_5%_0402_1/16W
Y
AGEO
RC0402JR-0730KL
70
1
R500
576 R
0402
RESISTOR SMD 576
R_1%_0402_1/16W
Y
AGEO
RC0402FR-07576RL
71
1
R501
38.3 K
0402
RESISTOR SMD 38.3
K_1%_0402_1/16W
Y
AGEO
RC0402FR-0738K3L
72
1
R502
510 R
0402
RESISTOR SMD 510
R_1%_0402_1/16W
Y
AGEO
RC0402FR-07510RL
73
1
R503
160 R
0402
RESISTOR SMD 160
R_1%_0402_1/16W
Y
AGEO
RC0402FR-07160RL
74
1
R504
4.7 K
0402
RESISTOR SMD 4.7
K_1%_0402_1/16W
Y
AGEO
RC0402FR-074K7L
75
1
R506
47 K
0402
RESISTOR SMD 47
K_5%_0402_1/16W
Y
AGEO
RC0402JR-0747KL
76
1
R508
1 K
0402
RESISTOR SMD 1
K_5%_0402_1/16W
Y
AGEO
RC0402JR-071KL
77
1
R510
0 R
0805
RESISTOR SMD 0
R_5%_0805_1/8W
UNI-ROY
AL
0805W8J0000T5E
78
1
U200
STWBC2
VFQFPN68L_L8_
W8_P0.4
FOR WIRELESS BA
TTERY
CHARGER TRANSMITTERS
Qi
ST
STWBC2
79
1
U201
STSAFE-A1
10
UFDFPN8
AUTHENTIFICA
TION, BRAND
PROTECTION SECURE
SOLUTION
ST
STSAFE-A1
10
80
1
U203
LMV321IL
T
SOT23-5L
Rail-to-rail operational amplifier
ST
LMV321IL
T
UM3286
STEV
AL-WBC2TX70 description
UM3286
-
Rev 1
page 52/84
51
53
